YC6GG -80 n5LC
Rated Hwj Chim: 80kw
GAS GATE: Natural Gas (Ch4Ntau dua los yog sib npaug rau 85%)
Voltage zaus: 400v / 50Hz
Khoom Taw Qhia
Lub c6gg -80 n5lc series roj tshuab tsim los ntawm yuchas, uas qhia txog kev tsim hluav taws xob ntawm tsev thiab txawv teb chaws thiab ua ke muaj xyoo kev thov kev lag luam. Chav tsev adopts cov roj ntsha paub tab, uas tau txheeb xyuas qhov tseeb los ntawm Yuchan cov kev txhim kho tshuab thiab ua kom zoo los ntawm cov qauv kev sib txuas ntawm kev txhim kho tshuab. Cov series cov roj txheem roj teeb muaj cov yam ntxwv ntawm kev tiv thaiv siab, muaj kev tiv thaiv ib puag ncig, thiab cov nqi kho mob ib puag ncig, thiab tuaj yeem ua tau raws li cov neeg siv sib txawv.
Siab ntseeg tau
Raws li kev tsim qauv thiab cov khoom tsim khoom ntawm cov khoom muaj zog, cov khoom siv lub tog raj kheej tseem ceeb, thiab cov pob hluav taws xob tseem ceeb, txhim kho kev ntseeg tau zoo thiab cov khoom siv tsis tau ntawm cov khoom lag luam.
01
Ua tau zoo thiab ib puag ncig phooj ywg
Los ntawm kev siv cov thev naus laus zis xws li cov roj ntsha ua haujlwm, thiab kev tswj cov roj qis, thiab kev txhim kho kev ua haujlwm qis thiab ruaj khov rau cov neeg ua haujlwm thiab thaj chaw ib puag ncig.
02
Tsawg tus nqi kho mob
Los ntawm kev npaj ua yuchai patented lub tog raj kheej Liner, Piston nplhaib, thiab valve sib tw thev naus laus zis, kev noj ntawm cov roj raj roj yog txo qis. Cov roj txheem tsim roj teeb tau nruab nrog universal thiab yooj yim tswj kom cov khoom siv, txo cov nqi kho cov nqi rau cov cuab yeej siv hluav taws xob.
03
Kev tiv thaiv kev nyab xeeb
Siv ib chav tsev ywj pheej thiab cov tswj lub zog, tswj hwm kev tswj hwm ruaj khov ntawm tag nrho cov txheej txheem, thiab lav kev nyab xeeb ntawm tag nrho lub tshuab.
04
Lub tshuab tsim fai fab
Lub tshuab hluav taws xob muaj qhov zoo ntawm cov zog muaj zog tiam, tsis tshua muaj kev kub siab, muaj kev ua kom zoo dua qub, thiab ua haujlwm ruaj khov avr parallel. Nws muaj thawj chav kawm kev ntseeg tau thiab lub durability, thiab tuaj yeem ua tau raws li qhov yuav tsum tau ua ntawm thaj chaw hnyav.
05
Cov Qauv Teeb Meem Ntau Lawm
|
Tsis muaj. |
Yam npe |
Ib yam |
Qho ntau |
Tsis muaj. |
Yam npe |
Ib yam |
Qho ntau |
|
1 |
Roj cav | Lub pej thuam |
1 |
7 |
Silencer, corrugated yeeb nkab | Chaw ua yeeb yam |
1 |
|
2 |
Lub tshuab tsim fai fab | Lub pej thuam |
1 |
8 |
Cia roj teeb | Chaw ua yeeb yam |
1 |
|
3 |
Dej Tank Radiator | Lub pej thuam |
1 |
9 |
Shock Absorber | Ib leeg |
6 |
|
4 |
Lub hauv paus | Lub pej thuam |
1 |
10 |
Random twj |
Chaw ua yeeb yam |
1 |
| 5 | Hauv Zos Txee | Lub pej thuam | 1 | 11 | Cov ntaub ntawv random | Chaw ua yeeb yam | 1 |
| 6 | Hlau Pab Pawg | Chaw ua yeeb yam | 1 | ||||
| Cov ntaub ntawv pabcuam sab nraud, cov lus qhia hluav taws xob, cov xov hluav taws xob, thiab peb phau ntawv pabcuam kev pabcuam. | |||||||
Tswj haujlwm
|
Kev muaj nuj nqi yooj yim |
Lub Hwj Chim Hloov, Pib, Nres, Nres Nres, Rau / Tawm Kev Tswj Xyuas, thiab lwm yam. |
|
Tso cai |
THASE voltage, cov kab hluav taws xob, tam sim no, cov hluav taws xob ua kom nrawm, ntsuas hluav taws xob, cov roj teeb pib, roj teeb hluav taws xob, thiab lwm yam. |
|
Kev tiv thaiv muaj nuj nqi |
Overspeed, underspeed, overvoltage, undervoltage, dhau zaus, overcurencent, ntau lub zog kub, them nyiaj qis, thiab lwm yam. |
Chav Tsev Loj & Nyhav
| Chav Tsev Net Loj & Net Nyhav | Ntev / A | Dav / b | High / c | Qho hnyav |
|
2400mm
|
980mm
|
1450mm
|
1200kg
|
Nco tseg: Cov ntaub ntawv saum toj no thiab cov ntaub ntawv yuav raug hloov kho nrog cov khoom hloov tshiab, thiab Yuchai muaj txoj cai los ua kev hloov pauv.
Cim npe nrov: YC6GG {{1} 5lc Qhib thav thav duab roj, Tuam Tshoj}}}}}}}}}}}}}}}}}}}}}}}}}}
| Generator teeb tsis | |
| Tus qauv |
YC6GG -80 n5LC
|
| Rated zog |
80kw / 100kva
|
| Nyob ceev |
1500r / min
|
| Cov Ntsuas Hluav Taws Xob |
400V
|
| Rated tam sim no |
144A
|
| Hov ntau |
50HZ |
| Pa | {{0 {}}. 8 (lagging) |
| Kev ua hauj lwm hluav taws xob |
Ntau dua los yog sib npaug rau 31.5%
|
| Kev siv roj tsheb tus nqi nyob rau hauv tag nrho cov chaw |
27.9m³/h
|
| Suab nrov |
Tsawg dua los yog sib npaug rau 115dB (a) @ 1m
|
| Pib txoj kev | Hluav Taws Xob Pib |
| Qho hnyav |
1200kg
|
| Lub cav tsis | |
| Tus qauv |
YC6G155n-D30
|
| Rated zog |
103kw
|
| Nyob ceev |
1500r / min |
| Daim thooj voos kheej |
6 |
| Ntaus | Hauv kab, plaub stroke, dej txias |
| Bore Stroke (hli) |
112mm × 132mm
|
| Kev hloov chaw (l) |
7.80L
|
| Compression Piv |
11.5:1
|
| Tswjhwm system | Ecu Hluav Taws Xob Tswj |
| Kev Siv Roj Tsheb |
Tsawg dua los yog sib npaug rau 0. 18g / kwh
|
| Lub muaj peev xwm txias (suav nrog radiator) |
51L
|
| Roj muaj peev xwm |
22L
|
| Overhaul lub sij hawm |
40000h
|
| Tsim tawm tshuab hluav taws xob | |
| Tus qauv |
Yc -80-4
|
| Kev sib txua | Peb theem plaub lub hlau hlau (Y-puab) |
| Kev cai siab tswj kev |
Avr
|
| Kev Tiv Thaiv Qib |
Meesp ip
|
| Kev thaiv kev theem |
F
|
| Kuaj mob | |
| Gas Calorific Tus Nqi |
9.1kev nws / m³
|
| Methane Files Cov Lus Qhia |
Ntau dua los yog sib npaug rau 95%
|
| Roj Cua |
-20} ~ 50 degree
|
| Roj av noo |
＜60%
|
| Roj nkag siab |
10 ~ 30kpa
|
| Huab cua nkag tsis zoo siab |
> {-3 kpa
|
| Kev ntsuas khaub ncaws rov qab siab |
<5kpa
|
| Lub Siab Lub Siab |
101.32kpa
|
| Ib puag ncig kub |
25 degree
|
| Tus txheeb ze cov av noo |
30%
|
| Qho siab |
Tsawg dua los yog sib npaug rau 1000m
|
| Nco tseg: Txhua cov ntaub ntawv ntawm cov roj txheem hluav taws xob tau ntsuas tau ntsuas hauv qhov chaw kuaj saum toj no. | |
